One-dimensional PSD features
- converts the position of a light or radiation spot into signal currents
- outstanding position resolution and linearity
- wide range of spectral response
- works with a wide range of light or radiation intensities
- fast response time (1 MHz!)
- measures light or radiation intensity and position simultaneously
- independent of light or radiation spot focus
- high dynamic range
s
PSD
Position non-linearity: +/-0.1%
Detector resistance: 50 kohmPart. No
DescriptionActive areaPackageS1-00011L2.5_CP22,5×0,6 mm14-pin DILS1-00651L2.5_CP12,5×0,6 mm4-pin DILS1-00031L5_CP25,0x1,0 mm14-pin DILS1-00091L5_CP15,0x1,0 mm4-pin DILS1-00051L10_CP210,0x2,0 mm14-pin DILS1-023610,0×2,0 mm1L10_SU70SMDS1-0006
1L20_CP320,0x3,0 mm22-pin DILS1-00071L30_SU230,0x4,0 mmsubstrateS1-02471L45_SU6945,0x3,0 mmsubstrateS1-024860,0×3,0 mm1L60_SU34substrate
PSD with stray-light elimination
Position non-linearity +/-0.1%
Detector resistance 200 kohmPart. No
DescriptionActive areaPackageS1-00901L5NT_CP15,0x0,25 mm4-pin DILS1-0061L5NT_CP25,0x0,25 mm14-pin DILS1-0067
1L10NT_CP210,0x0,5 mm14-pin DIL
PSD with Enhanced UV respons
Part. No
DescriptionActive areaPackageS1-00721L2,5UV_CP22,5×0,6 mm14-pin DILS1-00321L5UV_CP25,0x1,0 mm14-pin DILS1-00731L10UV_CP210,0x2,0 mm14-pin DILS1-00741L20UV_CP320,0x3,0 mm14-pin DILS1-0034
1L30UV_SU2
30,0×4,0 mmsubstrate
